Lamina PU Foam ( FormLine )
Prescribed for your needs...
Prescribed to meet the needs especially in the textile and footwear industries, FormLine adheres to the surface of fabric with the heat effect thanks to its proprietary special lamination additive.
Prescribed to meet the needs especially in the textile and footwear industries, FormLine adheres to the surface of fabric with the heat effect thanks to its proprietary special lamination additive. It is mainly produced in rolls and takes the first place in the domestic market in production of Form Sünger' lamina foam production.
Gallery
Lamina PU Sünger ( FormLine ) Technical Data
| UNIT | DENSITY | HARDNESS | COMPRESSION SET | TENSILE STENGHT | ELONGATION AT BREAK | TEAR RESILENCE | ||
|---|---|---|---|---|---|---|---|---|
| TS EN ISO 845 | TS EN ISO 2439 | TS EN ISO 1856 | ASTMD 3574 | TS EN ISO 1798 | ASTM D 3574 | |||
| Kg/m3 | N | %50 | N/CM3 | % | N/CM | |||
| 25% | 40% | 65% | ||||||
| 16 DURA LAMINE | 16±1 | 76 - 104 | 105 - 143 | 216 - 292 | MAX. 6 | > = 7 | > 160 | > = 2,5 |
| 20 DURA LAMINE | 20±1 | 117 - 159 | 151 - 205 | 294 - 398 | MAX. 6 | > = 7 | > 140 | > = 2 |
| 22 DURA LAMINE | 22±1 | 116 - 158 | 152 - 206 | 317 - 429 | MAX. 6 | > = 9,5 | > 110 | > = 2 |
| 22 Dn | 22±1 | 78 - 106 | 98 - 132 | 384 - 250 | MAX. 6 | > = 8 | > 150 | > = 2 |
| 24 Dn | 24±1 | 89 -121 | 115 - 155 | 201 - 271 | MAX. 6 | > = 8,5 | > 170 | > = 1,5 |
| 24 SOFT LAMINE | 24±1 | 46 - 62 | 65 - 88 | 117 - 159 | MAX. 5 | > = 5 | > 160 | > = 2 |
| 26 Dn | 26±1 | 89 - 121 | 115 - 155 | 208 - 282 | MAX. 6 | > = 8 | > 150 | > = 1,5 |
| 32 Dn | 32±1 | 107 - 145 | 129 - 175 | 251 - 339 | MAX. 6 | > = 9,5 | > 150 | > = 1,5 |
