Dura Form
Full support for your COMFORT…
DuraFORM, a foam technology used as filling and support material in the automotive, white goods, transportation, mattress and furniture industries, is a form with the highest hardness index among the conventional foam manufactured by Form Sünger.
Creating a hard surface area in all or certain parts of the product in areas where high hardness is required, DuraFORM adds high durability and ideal comfort to the product by demonstrating high hardness levels at lower densities.
Gallery
Dura Form Technical Data
| UNIT | DENSITY | HARDNESS | COMPRESSION SET | TENSILE STENGHT | ELONGATION AT BREAK | TEAR RESILENCE | ||
|---|---|---|---|---|---|---|---|---|
| TS EN ISO 845 | TS EN ISO 2439 | TS EN ISO 1856 | ASTMD 3574 | TS EN ISO 1798 | ASTM D 3574 | |||
| Kg/m3 | N | %50 | N/CM3 | % | N/CM | |||
| 25% | 40% | 65% | ||||||
| 14 Dn Mega | 14±1 | 103 - 140 | 132 - 179 | 266 - 360 | MAX. 6 | > = 6 | > 80 | > = 1 |
| 16 Dn Mega | 16±1 | 105 - 141 | 136 - 184 | 276 - 375 | MAX. 6 | > = 6 | > 100 | > = 1 |
| 18 Dn Mega | 18±1 | 129 - 173 | 162 - 220 | 310 - 420 | MAX. 5 | > = 7 | > 120 | > = 2 |
| 22 Dn Mega | 22±1 | 164 - 222 | 209 - 283 | 414 - 561 | MAX. 6 | > = 9 | > 90 | > = 1 |
| 14 Dn | 14±1 | 70 - 94 | 90 - 122 | 182 - 246 | MAX. 6 | > = 6 | > 100 | > = 1 |
| 16 Dn | 16±1 | 68 - 92 | 89 - 121 | 178 - 240 | MAX. 6 | > = 6 | > 110 | > = 1 |
| 18 Dn | 18±1 | 86 - 116 | 110 - 150 | 205 - 278 | MAX. 6 | > = 6,5 | > 100 | > = 1 |
| 20 Dn | 20±1 | 125 - 170 | 149 - 202 | 296 - 400 | MAX. 6 | > = 8 | > 100 | > = 1,5 |
| 22 Dn | 22±1 | 135 - 183 | 174 - 236 | 335 - 454 | MAX. 6 | > = 8,5 | > 88 | > = 1,3 |
| 24 Dn | 24±1 | 144 - 195 | 178 - 241 | 341 - 461 | MAX. 6 | > = 8 | > 105 | > = 1 |
| 26 Dn | 26±1 | 155 - 210 | 194 - 263 | 348 - 471 | MAX. 6 | > = 9 | > 85 | > = 0,80 |
| 28 Dn | 28±1 | 159 - 216 | 204 - 276 | 355 - 481 | MAX. 6 | > = 9 | > 80 | > = 0,80 |
| 30 Dn | 30±1 | 177 - 239 | 215 - 291 | 354 - 478 | MAX. 6 | > = 8 | > 90 | > = 1 |
| 32 Dn | 32±1 | 171 - 231 | 217 - 293 | 367 - 497 | MAX. 6 | > = 9 | > 85 | > = 1 |
| 35 Dn | 35±1 | 173 - 235 | 207 - 281 | 327 - 443 | MAX. 6 | > = 9 | > 115 | > = 1,5 |
| 40 Dn | 40±1 | 199 - 269 | 247 - 334 | 429 - 581 | MAX. 6 | > = 9 | > 90 | > = 1 |
| 50 Dn | 50±1 | 310 - 420 | 390 - 528 | 814 - 1102 | MAX. 5 | > = 19 | > 120 | > = 1,5 |
| 60 Dn | 60±2 | 357 - 483 | 428 - 578 | 696 - 942 | MAX. 6 | > = 16 | > 120 | > = 1,45 |
| 70 Dn | 70±2 | 452 - 612 | 562 - 760 | 1133 - 1533 | MAX. 6 | > = 20 | > 80 | > = 1 |
